Pipe end milling system

Pipe end milling system

Introduction:

Pipe End Milling is a precision machining process used to prepare the cutback of 5LPPE (Syntactic) foam insulated pipes, prepared for the joint welding/coating process.



Solution:

The Pipe End Milling System offers a comprehensive solution for cutback preparation of 5LPP foam coated pipes. It is engineered to mill with dimensional accuracy and exact angles, creating uniform cutback profiles. This system can handle a wide range of pipe sizes, making it a versatile tool for various pipeline projects.



Key Features:

  • Precision control system for accurate depth and angle adjustments
  • Automated operation with programmable settings



Benefits:

  • Robust design minimizes vibration, enhancing machining accuracy
  • Versatile machining options accommodate various pipe dimensions
  • Modular design
  • Compact footprint optimizes floor space utilization in production facilities
  • Integrated safety features including emergency stops and protective guards



How It Works:

Both foam cutting carriages are driven from the home position towards each pipe end. The carriage stops when the pipe ed is reached. Subsequently the pipe starts rotating. When the pipe rotates, the pipe contact slide is pushed against the bare steel pipe end. Subsequently the traverse slide (Z-direction) moves to align the cutting tool with the start of the foam section. Next, the cross slide (X-direction) moves the cutting tool against the rotating pipe. The traverse slide and cross slide move the cutting tool along the pipe, cutting the required shape in the foam layer.



The Full Scope:

The Pipe End Milling System can be installed in a 5LPP (syntactic) foam pipe insulation plant. When installed in an existing facility, additional equipment which might be required are:

  • Pipe handling and transport systems
  • Automatic pipe loading/unloading



Innovate better together!

By mutual learning, we have grown to who we are today. A trustworthy supplier of a multitude of automated solutions. Do you want to optimize performance and reduce risks? Send an email to sales@selmers.com or call +31(0)251211999, or fill in a contact form via https://www.selmers.com/contact and we’ll get back to you.

Pipe End Milling System

Pipe diameters: 406 mm – 1,219 mm (16″ – 48″)Pipe lengths: Up to 13.2 m (longer on request)Insulation thicknesses: Up to 100 mm

* other specifications upon request
